PRICE : US $2,290 /UNIT.

Website : WWW(dot)measure-tools(dot)COM .

Item Condition : Used .

You are bidding on used Leica TCR305 prismless total station with 5" angle accuracy, continuous and absolute encoders. Unit will shoot up to 260' in prismless mode with the visible laser pointer. Data transfer to a personal computer or any data collectors is possible with the RS-232Cinterface, and also memory on board can store up to 8000 fix points, which will save you the purchase of data collectors.  Unit features continuous drives for horizontal and vertical motions (tangent screws) without using locking system. To eliminate power problem in field unit can be power up either with rechargeable camcorder battery or 6X AA batteries.

Item Specifications :

Magnification: 30X

Image: Erect

Minimum focusing distance: 1.7m/5.58'

Angle accuracy: 5"

Angle minimum display reading: 1"

Angle detecting system: Dual-side reading

Angle/Dist. units: Switchable between degrees, mil or gon, meter or feet, US/ft-International

Distance measurement: 1 Prism: 8,200', 3 Prism: 9,700', Mini Prism: 2,600'

Distance measurement to prismless mode: 260'

Distance measurement precision: ±(2mm+2ppm)

Distance measuring time: 3s+every 0.3s tracking mode

Distance measuring time: 1s+every 0.5s coarse mode

Distance minimum display: 1mm/0.003ft

Display: Single

Internal memory: Surveying data + coordinates data total 4000 data blocks or 8000 fixpoints

Data input/output: RS-232C

Compensator: Oil dual axis

Compensating range/Accuracy: ±4'/1.5"

Weight: 5.2kg, 11.5lbs including tribrach and battery

Auction Includes :

Leica TCR305 Total station

Leica Tribrach

2X Battery GEB111

Leica charger

Leica cradle

Leica rain cover

Leica sunshade (objective hood)

Original carrying case

Owner's manual
